BW Technologies Gas Alert Micro Clip XT multi gas monitor
Item #:
XXYY-MC2
Brand:
BW Technologies
Share this product:
Economical Multi-Gas Monitor
Features:
- Rugged, ultra-compact (4.2 x 2.4 x 1.4 in / 10.7 x 6.0 x 3.6 cm) and lightweight (5.6 oz. / 160 g)
- Simple one-button operation
- Standard datalogger (16 hours) and eventlogger (10 events)
- Durable, stainless steel alligator clip
- Integral concussion-proof boot for the most rugged environments
- Continuous LCD shows simultaneous gas concentrations for H2S,CO, O2, and combustibles (0-100% LEL or 0-5.0% Methane)
- Powered by a lithium polymer battery (run-time typically 14 hours;recharge in less than 3 hours)
- Provides 95 dB alarm tone and bright wide-angled alarm bars
- Equipped with internal vibrating alarm for high noise areas
- Backlight: in alarm (auto) and on demand reactivation
- Four alarm levels: Instant Low and High Alarm for all gases;TWA (time weighted average) and STEL (short term exposure limit) for H2S, CO; OL (over limit alarm)
- Simple automatic calibration procedure
- Fully compatible with BW's MicroDock II automatic test and calibration system
- Records TWA, STEL and maximum exposures to gas and displays readings on command
- User selectable options include: confi dence beep, latching alarm, calibration due date, bump due date, "SAFE" display function, multi-language, span concentration values, combustible sensor measurement selection (0-100%LEL or 0-5.0% v/v methane) and stealth mode
- Full function self-test of: sensor, battery, circuitry and audible/visual/vibration alarms
- Delivered ready for use with sensors, lithium polymer battey, stainless steel alligator belt clip, calibration hose/cap and instructions
Size | 4.4 x 2.4 x 1.1 in. / 11.3 x 6.0 x 2.9 cm |
Weight | 6 oz. / 171 g |
Temperature | -4 to +122°F / -20 to +50°C |
Humidity | 0% - 95% RH (non-condensing) |
Alarms | - Visual, vibrating, audible (95dB) - Low, High, STEL, TWA, OL (over limit) |
Tests | Audible/visual alarms on activation, sensors, battery and circuitry (continuous) |
Pump | Compatible with the Sampler motorized sampling pump |
Typical battery life | 10 hours (typical); recharges in less than 4 hours |
User options | Confidence beep, Set STEL interval, Sensor on/off, Latching alarms, Safe display mode, Stealth mode, Calibration lock, Auto zero on start up, O2 auto calibration on start up, Set bump test interval, IntelliFlash interval, Combustible gas measurement (% LEL or % by volume methane), User-settable calibration gas level, Force bump test when overdue, Force calibration when overdue, Low alarm acknowledge, Language choices (five), Set custom start up message |
Warranty | Full 2 year warranty including all sensors |
Gas | Measuring Range | Resolution |
H2S | 0-100 ppm | 1 ppm |
CO | 0-500 ppm | 1 ppm |
O2 | 0-30.0% | 0.1% |
Combustible gases | 0-100% LEL 0-5.0% v/v |
1% 0.1% |
Datasheets & User Manuals
Questions & Answers
2 Questions &
2 Answers
Alex Smither
from Lagrange, Ky asked:
December 21, 2017
I have a O2 sensor that has gone bad. It says 40XV CiTiceL, Oxygen, AAY80-390-BW. What is the replacement number?
1 Answer
Hi Alex, the replacement sensor that you need is the SR-X2V oxygen sensor.
Submitted by:
Customer Service
on April 5, 2018
maroun saba
from melbourne australia asked:
July 21, 2013
Just wondering if this product comes calibrated and ready to use?
1 Answer
Yes, the monitor does come calibrated and ready to use right out of the box. A calibration cert will also be included.
Submitted by:
Customer Service
on April 5, 2018
