Model 291

291 Hand-held Manual Ranging Clamp-on DMM by Test Products International

Digital Clamp-On Meter Amp Plus. The 291 is a hand-held manual ranging clamp-on DMM, an affordable choice offering measurements in all basic electrical functions.

The 291 is a hand-held manual ranging clamp-on DMM. The 291 is an affordable choice offering measurements in all basic electrical functions.

• Bar Graph: When measuring frequency, bar graph indicates current level.
• Peak Mode: For start-up and inrush currents.
• Sleep Mode: Preserves battery life.
• Data Hold: Holds the reading on the display for easy viewing.

Features:

• Agency UL Listed to U.S. and Canadian Safety Standards. Meets CE and IEC 1010.
• 4000 Count Improves the resolution on all functions and ranges.
• Data Hold Maintains the reading on the display for hard to reads areas.
• Peak Mode Measure the inrush current of motors, relays and solenoids.
• Sleep Mode Automatically powers down after 10 minutes of inactivity
• 700 Amps AC
• Measure AC/DC volts, resistance and continuity
• CAT III 600 V rated
• cULus 61010
• 3-year limited warranty

Applications:

• Thermocouples in furnaces and gas appliances
• Heat anticipator current in thermostats
• Test line and control voltage
• Compressor winding resistance
• Contactor and relay coil resistance
• Motor and compressor startup current
• Continuity of wiring
• Measure line current
• Test continuity of circuit breakers and fuses
• Measure voltage of direct drive DC motors
• Measure power supply voltage

The 291 comes complete with the following accessories:

• Carrying Pouch
• Test Lead Set
• Temperature Probe
• Instruction Manual
• Battery
