Crowcon Hydrogen Sulphide Open Path Detector (30-100 m), UV Flash

Item #:

414

Brand:

Crowcon

Ask an Expert

Our tech experts are ready to help!

1-866-4 JJSTECH (1-866-455-7832)

Email Us

Share this product:

Description

414 Hydrogen Sulphide Open Path Detector (30-100 m), UV Flash by Crowcon

Open Path IR or "line of sight" optical gas detectors offer reliable detection of hydrocarbon gas emmissions over large areas. OPIR detectors detect gas hazards ranging from low level Parts Per Million (PPM) levels to Lower Exposure Limit (LEL) levels in hazardous areas.

Features:

Hydrocarbon and H2S versions available
Explosion proof to ATEX, UL and GOST-R Standards
Choice of models for ranges of 0.6m up to 140m
Aluminium or stainless steel construction
4-20mA or RS-485 operation, with alarm and fault relays available

Specifications

GENERAL SPECIFICATIONS

Detected Gases

Detection of toxic gases such as hydrogen sulfide (H2S), Ammonia (NH3) and aromatic hydrocarbons such as Benzene, Toluene, Xylene, Styrene, etc.

Detection Range and Response Time

Model No.	410	411	412	413	414
Distance (ft)	3.3-13	6.6-26	23-82.5	49.5-165	99-330
Distance (m)	1-4	2-8	7-25	15-50	30-100
Response Time	1 sec.	2 sec.	5 sec.	10 sec.	10 sec.
Detected gas	H2S	H2S	H2S	H2S	H2S

Model No.	420	421	422	423
Distance (ft)	3.3-13	6.6-26	23-82.5	49.5-165
Distance (m)	1-4	2-8	7-25	15-50
Response Time	1 sec.	2 sec.	5 sec.	10 sec.
Detected gas	Ammonia, Benzene/Xylene, Toluene, CS2

Immunity to False Alarm

Is not influenced by solar radiation, hydrocarbon flames and other external IR radiation sources.

Spectral Response

200-300 ?m

Sensitivity Range

0-500 PPM.m Standard
0-200 PPM.m by dip-switch setting

Displacement/Misalignment Tolerance

� 1/2?

Drift

Long-term � 5% of full scale

Temperature Range

-40?F (-40?C) to 131?F (55?C)

ELECTRICAL SPECIFICATIONS

Power Supply

Standard - 24 VDC (18-32 VDC)

Power Consumption

Detector: 150mA @ 24 VDC (200 mA Peak)
Source: 100mA @ 24 VDC (220 mA Peak)

Electrical Connection

2 x 3/4? - 14NPT conduits
or 2 x M25 x 1.5 mm ISO

Electrical Input Protection

Complete electrical interface protection against reversed polarity voltage, surges and spikes according to MIL-STD-1275A

Electromagnetic Compatibility

EMI/RFI protected CE Marked

OUTPUTS

4-20mA

The 4-20mA current output is source configuration Resistance Loop 100-600

RS-485

Serial communication for full control with maintenance and trouble shooting facility can be integrated for a network of max 64 detectors

Relays

	Type	Normal Position	Maximum Ratings
Alarm	SPDT	NO, NC	2A at 30VDC or 0.5 at 250 VAC
Accessory	SPST	Open	5A at 30VDC or 250VAC
Fault	SPST	Closed	5A at 30VDC or 250 VAC

MECHANICAL SPECIFICATIONS

Dimensions

5.2" (132mm) x 5.2" (132mm) x max. 11" (280mm)

Weight

Detector: max 8.8 lb (4 kg) Source: max 10.8 lb (4.9 kg)
Detector: max 14.3 lb (6.5 kg) Source: max 16.7 lb (7.6 kg)

Mechanical Design

The standard detector housing is heavy-duty, copper-free (less than 1%) aluminum. The housing is finished in white epoxy enamel and is also available in 316L Stainless Steel* upon request. * Carries an additional charge.

Environmental Standards

Meets MIL-STD-810C for Humidity, Salt & Fog, Vibration, Mechanical shock, High Temp, Low Temp

Water and Dust Tight

IP66 and 67
NEMA 250 6P

HAZARDOUS AREA APPROVALS

ATEX / Cenelec

EX II 2G EExd IIB + H2 T6 (55?C)
EX II 2G EExde IIB + H2 T6 (55?C)

UL No. - E209870, Class I Groups C and D Hazardous Location
