Kanomax Airborne Particle Counter (28 Liter/Min) (1 CFM) - 3905
Item #:
3905
Brand:
Kanomax
Share this product:
3905 Airborne Particle Counter (28 Liter/Min) (1 CFM) by Kanomax
Applications:
- Cleanroom verification
- Clean Bench verification
- Filter Testing
- Facility Certification
- Food Process Investigation
- Hospital Surgical Room
Features:
- 50 L/min (1.77 cfm) Flow Rate - Model 3910
- 28.3 L/min (1.0 cfm) Flow Rate - Model 3905
- Compliant with ISO 21501-4 and 21 CFR Part 11
- Simultaneous measurements of 6 particle sizes
- Store up to 10,000 Measurements
- Stainless Enclosure
- 2 Year Warranty
Benefits:
- Featherlight with an ultra-small footprint
- Large Color Touch Screen
- Multi-parameter: Particle, Airflow, Temperature, Humidity, Differential Pressure
- Mulit-standard mode: ISO 14644, FS 209E, BS 5295, EC GMP
| Light Source | Laser diode |
| Particle Channel Sizes | 0.3, 0.5, 1.0, 3.0, 5.0, 10.0 micron meters |
| Counting Efficiency | 50% 20% at 0.3 micron meters, 100% 10% at 0.5 micron meters |
| Flow Rate | 28.3 LPM (1.0 CFM) |
| Concentration Limit | More than 500,000 particles/ft3 at 10% coincidence loss |
| Zero Count Leve | Less than 1 count per 5 minutes |
| Environmental Sensor | Air velocity, temperature, relative humidity, and pressure |
| Vacuum Source | Internal pump |
| Exhaust | Internal HEPA filtered to more than 99.97% at 0.3 micron meters |
| Printer | Built-in thermal printer |
| Display | 6.4 inch, color touch screen |
| Enclosure | Stainless Steel |
| Interface | Ethernet, USB, Memory card slot (MMC) |
| Data Storage | Up to 10,000 sample records |
| Security | Password authentication and management, secure data, and audit trails (meets 21 CFR Part 11 compliance) |
| Reports | ISO 14644-1, EU GMP, FS209E, and New Chinese GMP |
| Standards | ISO 21501-4, JIS B9921, CE |
| Power Supply | Li-ion battery or AC adapter (100 to 240V) |
| Battery | Removable/rechargeable Li-ion batteries (2 battery slots) |
| Operating Range | 50 to 104°F (10 to 40°C), 20 to 85%RH with no visible condensation |
| Storage Range | 14 to 122°F (-10 to 50°C), up to 98%RH with no visible condensation |
| Dimensions (H x W x D) | 7.9 x 8.1 x 7.9 inches (200 x 205 x 200 mm) without handle |
| Weight | 14.2 lbs (6.4 kg) with two batteries |
| Warranty | 2 years |
| Included Accessories | Quick-start guide, operation manual, zero filter, 1 x Li-ion battery, AC adapter, sampling tubing data storage card, isokinetic probe, data processing software, printer paper, NIST Certificate |
| Optional Accessories | Carrying case, spare li-ion battery, tripod, external battery charger, ClimomasterTM probe (air velocity, temperature, relative humidity), pressure sensor, alarm output cable, IQ/OQ validation document |
