Oakton pH Electrode, In-line, Double-junction, No ATC 10-ft Cable, BNC - WD-27001-90
Item #:
WD-27001-90
Brand:
Oakton Instruments
Share this product:
WD-27001-90 pH Electrode, In-line, Double-junction, No ATC 10-ft Cable, BNC by Oakton
In-line electrodes operate from 32 to 212°F (0 to 100°C) and have a chemical-resistant PVDF housing with a 1/2" NPT(M) thread. Housing measures 4" x 15/16" diameter. Electrode extends 1" beyond housing. Maximum pressure 100 psi. Measure pH from 0 to 13.
Note: 100 Ω RTD ATC elements are platinum and conform to DIN curve 43760. ATC connector is miniature audio plug.
Connector for the 1 kΩ RTD and the 3 kΩ Balco ATC elements is a spade lug.
Connector for 100 kΩ
Integral, one-piece electrode and housing for installation convenience
- Choose from single-junction or double-junction designs
- Options of BNC or stripped and tinned ends
Electrode Type | Double junction |
Electrode Body Material | PVDF |
Min pH (pH) | 13 |
Max Temperature (° C) | 80 |
Connector | BNC |
Description | pH electrode, in-line, double-junction, no ATC 10-ft cable, BNC |
