Kanomax Handheld Odor Meter - OMX-ADM
Item #:
OMX-ADM
Brand:
Kanomax
Share this product:
OMX-ADM Handheld Odor Meter by Kanomax
Handheld Odor Meter is the most popular simplified tool for odor analysis, which indicates the relative strength and odor classification numerically by comparing the odor gas and purified air.
Features:
- Numerical value for relative strength of smell
- Numerical value for classification of smell
- Handheld Odor meter is ideal for Before and After applications, such as air purification and cleaning service.
- Real-time sampling mode displays odor change continuously
- Memory sampling mode saves data based on the selected sampling rate. (up to 32732 data, 511 files)
- Battery operated with 7 hrs continuous usage
Applications:
- OMX-SRM: Finding odor source at factories, incinerator, plants, or effluent treatment facility
- OMX-ADM: Evaluation for deodorizing at hospitals or nursing homes, Suitable for putrid odor such as ammonia
- OMX-TDM: TVOC measurement for monitoring IAQ condition
Includes:
- Suction nozzle
- AC adapter
- AA batteries
- USB cable
- Air purifying unit
- Activated carbon (50cc/bag)
- Replacement filter for air purifying unit
- Replacement filter for suction nozzle
- Operation manual
Model |
OMX-SRM |
OMX-ADM |
OMX-TDM |
Detection Method |
Two Semiconductor Gas Sensors |
||
Sampling Method |
Continuous Sampling with Built-in Air Pump |
||
Object Gas |
Ethanol, Acetone, Hydrogen, etc |
Hydrogen Sulfide, Methyl Mercaptan, Ammonia, etc |
TVOC (Toluene), etc |
Odor Strength Level |
0.0 to 999 |
0 to 999 |
0.0 to 9999 (µg/m3) |
Classification |
Class 0 to 90 |
Odor Intensity 2.5 to 5.0 |
n/a |
Power Supply |
4 x AA batteries or AC adaptor *Battery life for continuous measurement is approx. 7 hours |
||
Memory Capacity |
Up to 32732 data |
||
Storage Temperature |
0 to 40 °C (32 to 104 °F) * No condensation |
||
Operating Temperature |
-10 to 50 °C (14 to 122 °F) * No condensation |
||
Dimensions |
74 (W) x 167.5 (L) x 35 (H) mm |
||
Weight |
250g (without batteries) |
