Extech 382091 1000A 3-Phase Power Analyzer/Datalogger (50 Hz)
Item #:
EXT-382091
Brand:
Extech
Share this product:
382091 1000A 3-Phase Power Analyzer/Datalogger (50 Hz) by Extech
Features
- Large backlighting LCD displays 10 parameters simultaneously (kW, kVAR, kVA, PF plus the voltage and current of the 3 phases)
- Up to four current probes can be connected to the analyzer
- Clamp-on True RMS power measurements with software for Harmonics analysis
- Displays Active Power (kW), Apparent Power (kVA), Reactive Power (kVAR) and Power Factor
- Current measurements to 1000A and Voltage measurements to 600V
- kWH, kVARh and kVAh energy measurements
- Automatically logs up to 20,000 sets of measurements and manually logs up to 99 sets
- Programmable Start/Stop datalogging times
- PC interface with Windows® 95/98/NT/2000/ME/XP compatible software for single and three phase voltage/current Waveform display and Harmonic analysis
- Phase sequence measurements
- Auto power off with disable feature
- CAT III-1000V, UL Listed; CE approved; 1yr warranty
Applications
- AC Power Quality Evaluation
- Harmonic Analysis
- Motor/Generator Installation
- Energy Audits
Includes
- 4 current clamps
- 4 voltage leads with alligator clips
- 8 AA batteries
- AC adaptor
- Software
- PC interface cable
- Case
| Maximum voltage between voltage input terminals and earth ground | 1000 Vrms |
| Maximum rated working voltage for current input | 0.35Vrms |
| Maximum current for current probe | 1000A rms |
| Display | Ten (10) 4-digit LCD displays (maximum reading 9999) |
| Batteries | 8pcs, 1.5VAA |
| Battery life | approx. 50 hours |
| AC Adaptor | 12V DC, 300mA |
| Auto power off | After approx. 30 minutes |
| Low battery indication | Battery symbol is displayed when battery voltage falls low |
| Backlight display time | Automatically turns off approx. 30 seconds |
| Sampling rate | Approx. 1 display update every 2 seconds (digital display) |
| Waveform and harmonic analyzer | 54 samples per period |
| Current probe jaw opening diameter | Cables ψ40mm |
| Operating temperature and humidity | 32 to 104°F (0 to 40°C); R.H. <80% non-condensing |
| Temperature coefficient | 0.1 x (specified accuracy) / <64 or >82°F (<18 or >28°C) |
| Storage temperature and humidity | 14 to 140°F (-10 to 60°C); R.H. < 70% non-condensing |
| Dimensions (meter) | 9.2(L) x 4.6(W) x 2.1(H)"; [235(L) x 117(W) x 54(H)mm] |
| Dimensions (Current probes) | 7.6(L) x 3.5(W) x 1.6(H)"; [193(L) x 88(W) x 40(H)mm] |
| Weight | Meter: approx. 25.8 oz (730g); Current probe: approx. 11.6oz (333g) |
| Safety | This meter is intended for indoor use and protected, against the users, by double insulation per EN61010-1 and IEC61010-1 2nd Edition (2001) to CAT III 1000V; Pollution Degree 2. The meter also meets UL 61010A-1, First Edition |
| UL Listed | The UL mark does not indicate that this product has been evaluated for the accuracy of its readings. |
