Citizen Scale VIS 7220G VIS Spectrometer
Item #:
CS-VIS-7220G
Brand:
Citizen Scale
Share this product:
VIS 7220G VIS Spectrometer by Citizen Scale
Features:
- Calibration curve can be set up by either measuring or entering up to 10 standards or entering K and B factors directly via the keyboard.
- Microprocessor control, 16 x 2 LCD display.
- Auto zero and auto 100%T adjustment provided.
- Standard manual 4-cell holder accommodates cells from 5-50mm and changeable to long path length cell holder of 100mm.
- Parameters can be saved for later use; Up to 10 calibration curves can be stored and edited for user's convenience.
Model | VIS 7220G |
Wavelength | 320 ~ 1100nm |
Wavelength Accuracy | ± 2.0nm |
Wavelength Reproducibility | 1nm |
Monochromator | Single-Beam, C-T type, grating 1200L/mm |
Photometric Accuracy | ± 0.5%T |
Photometric Reproducibility | 0.3%T |
Stray Light | 0.1%T (NaNo2 at 340nm) |
Spectral Bandwidth | 2nm (1,4,5nm optional) |
100%T Stability | 0.001A/30min (at 500nm, after warming up) |
Operation Mode | T, A, C, E, |
Photometric Range | -.0.3 ~ 3A |
Display | 16 x 2 LCD |
Detector | Silicon Photodiode |
Light Source | Tungsten Halogen lamp |
Data Output | RS-232 interface (USB Port), Printer Port |
Power Requirement | 110 ~ 220V, 50/60Hz |
Dimension | 530 x 410 x 210mm |
Net Weight | 15 kg |
