Blackline Device, Loner M6i Cellular, North America - M6i-NA

Blackline Device, Loner M6i Cellular, North America - M6i-NA

$449.00

Discontinued


M6i-NA Device, Loner M6i Cellular, North America by Blackline Safety

Employees working alone within hazardous environments face the risk of injury, health incidents and physical assault in the workplace. Blackline's Loner® M6i is ATEX certified intrinsically safe and continuously monitors the safety of lone workers and alerts monitoring personnel in real-time if the unexpected occurs. Respond in the fastest time possible—to your employee's precise location with Loner M6i.

Blackline designed Loner M6i from the ground up to be the most advanced safety monitoring solution available. Designed for industrial applications, it incorporates 3G wireless communications, advanced positioning technology, automatic incident detection and manually-triggered safety features—all in a compact and easy-to-use package.

Features include True Fall Detection®, man-down (motionless) detection and a failed employee check in. Loner M6i incorporates an intuitive emergency latch that is easier to trigger than a button and can be accessed if the employee's vision is impaired. A silent emergency button is also available for duress situations.

Loner M6i incorporates GPS for precise outdoor positioning and is compatible with Blackline's Loner Beacon positioning technology for locations throughout and nearby buildings and facilities where GPS signals are imprecise or not available.

Blackline's Silver service plan enables organizations to self-monitor their lone workers using Blackline's Loner Portal web application. Our Gold service plan delivers around-the-clock live safety monitoring, leveraging Blackline’s in-house Safety Operations Center or one of our Alarm Receiving Center partners.

To empower emergency response, Silver Voice and Gold Voice service plans are available, connecting monitoring teams to an employee in need of help via built-in speakerphone. Loner M6i achieves all requirements of the British Standard BS 8484.

Highlights

  • Global awareness of your workforce's real-time safety
  • Improves safety awareness of remote workers
  • Quickly mobilize an emergency response by mapping worker locations in Loner Portal
  • Real-time safety alerting increases awareness of safety incidents
  • Achieves regulatory compliance as required in some regions
  • Reduces mobile worker anxiety about safety
  • An automated system that does not require manual worker check-in
  • Immediate alert is triggered when the worker is incapacitated
  • High capacity 1000 mAh battery provides 10 hour operation
  • Customizable location scheduling provides bread-crumb of worker locations
  • Easy training for workers and monitoring personnel
  • Affordable for small both business or enterprise deployment
  • Compatible with Loner Beacon indoor / outdoor location technology
  • Loner Background Services alert monitoring personnel even when Loner Portal is not used
  • Emergency escalation list provides multiple layers of alerting to ensure an incident is addressed
  • Loner Web Services enable software developers to integrate safety monitoring within a call center
  • Easy-to-use web-based Loner Portal for efficient mapping and setup
  • Customizable Loner Portal account implementation for diverse customer needs
  • Sharing of Loner devices across multiple Loner Portal user accounts
  • Firmware upgradable over-the-air accommodates future enhancements
  • Web-hosted Loner Portal user account-no software to install

Features

  • Intrinsically Safe
  • True Fall Detection
  • No-Motion Detection
  • Employee Check-in
  • Emergency Latch
  • Silent Emergency Request
  • GPS Location Technology
  • Indoor Location Technology
  • Durable and Weatherproof
  • Loner Portal
  • Live Response
  • Two-Way Voice Calling
Size & Weight Size: 63 mm x 107 mm x 22 mm (2.48" x 4.213" x 0.87")
Weight: 137 g (4.8 oz)
Safety Monitoring Features Fall detection technology: Tri-axis accelerometer, tri-axis gyro, software processing
Emergency latch: Pull latch to trigger alert
Silent emergency: Press & hold check-in button to trigger alert
Worker motion monitoring: Configurable time window (1-30 min, or off)
Worker check-in: Required check-in period (5–180 min, or off)
Voice calling: Two-way and one-way (listen-only) phone calling (requires a voice-enabled service plan)
Buttons & Indicator Lights Power button: Power on/off
Check-in button: Check-in/silent emergency
Emergency latch: Send emergency alert
Red indicator light array plus vibration and beeper: Safety alert triggered
Blue indicator light array plus vibration and beeper: Incoming voice call
Blue indicator light: Alert has been acknowledged in the portal
Green SureSafe light: Blinking (powered), continuous (connected)
User Notification Indicators: Speaker, LEDs, and vibration motor
Speaker sound pressure level: ~90 dB @ 10 cm (~90 dB @3.94")
Voice calling: Speakerphone and phone modes
Wireless Communication Radio: Dual-band 3G (1900, 850 MHz)
Antenna: Internal dual-band
Bidirectional communication: Yes
Firmware upgrade over-the-air (FOTA): Yes
Location Technology GPS Radio: 48-channel high sensitivity, mobile assisted
Remotely-assisted GPS: Yes
GPS Accuracy: ~5 m (16 ft) Outdoors
GPS Real-time location turnaround time: ~20 seconds
Loner Beacon compatible: Yes
Alert Messages Fall detected
Eemergency latch
Silent emergency
No-motion
Missed check-in
Voice call alert
Low battery
Power off
Power & Battery Rechargeable Li-ion battery: 1200 mAh Li-ion
Battery Life: 20 hours continuous operation at 20° C (68° F)
Charging connector: 4-pin sealed connection
Environmental Storage temperature: -30°C to 75°C (-22°F to 167°F)
Operating temperature: -20°C to 55°C (-4°F to 131°F)
Charging temperature: 0°C to 45°C (32°F to 113°F)
Ingress Protection: Designed to meet IP65
Approvals FCC Part 15 Subpart B, FCC ID: XPYSARAU260, Industry Canada 8595A-SARAU260
Designed to meet BS 8484
Device Requirements Blackline Safety service plan
3G wireless communication coverage
GPS signal coverage required for GPS locating
Loner Beacon signals for precise indoor positioning
Warranty One-year limited factory warranty
Wireless coverage and service plans Wireless coverage: ~200 countries
Service plan options: Silver (for self-monitoring) and Gold (24/7/365 live monitoring included), with and without voice calling
Contact Blackline for further details
Loner Portal Web Application Features include: Alarm banner, initiate voice call, event history, device location mapping, device management, alert & notification settings, and more.
