GrowControl GCXmini Cultivation Controller by Agrowtek

GrowControl™ GCXmini Cultivation Control Systems have all of the same software features as the standard GCX and GCX+ models, but with a smaller screen and device count. The GCXmini is the perfect controller for a single zone in commercial environments, or as a complete control system for a hobby garden.

Built on over a decade of commercial experience, Agrowtek's GCX controllers are the most advanced and economical in the industry. Up to eight (8) GrowNET devices of your choice can be connected to the GCXmini system allowing many configuration options from a basic multi-zone control for climate or irrigation, to a fully loaded single-zone.

Standard Ethernet network interface connects the GCXmini to the internet for free email alerts, remote access and online updates. USB ports for data logging to memory stick, optional WiFi module and more.

Features

  • Connect Eight (8) Devices Sensors, I/O Modules, Dosers, etc.
  • 8 GrowNET Ports for Devices
  • Multi-zone Capable
  • Expandable Add Devices as Your Needs Grow
  • Easy to Setup & Operate Intuitive Interface, On-screen Help
  • Quad-Core Processor Efficient & Powerful
  • Internet Enabled Email Alerts, Remote Access
  • WiFi optional
  • No Software to Install No Computer to Crash
  • Powder-Coated Aluminum Tempered Glass Screen
  • Made in USA
  • 3-Year Warranty

Standard Functions

  • Temperature Control: Heating & Cooling
  • Humidity Control: Humidify & Dehumidify
  • CO2 ppm: Injection & Exhaust
  • Nutrient & pH Dosing
  • Lighting Control: On/Off, Dimming, Spectrum
  • Cropsteering & Irrigation: Pump & Valve Control
  • Timers: 24-Hour, Repeat Cycle, etc.
  • Motor Position Controls: Black-Out, Ridge, Sidewall
  • Water Tanks: Level Control & Management
  • Math: Sum, Difference, Average, etc.
  • Advanced Logic: And, Or, Not, etc.
  • Recipes: Schedule Automatic Changes
Input Power 24 Vdc, 2.5A Max
Included Power Supply UL Listed Class II Limited Energy Power Supply
90-265VAC Input, 24Vdc 2.5A Max Output
Control Interface GCX: 10.1" (1024 x 800) Capacitive Touch Screen
GCX+: 15.6" (1920 x 1080) Capacitive Touch Screen
GrowNET™ Ports / Devices GCX: 8 / 100
GCX+: 16 / 200 (100 devices per 8-port bus)
Network Communication 10/100 Ethernet (RJ-45) WiFi (optional, USB)
USB Ports 4x USB A 2.0 Host, 1x USB B Slave (boot loader)
Processor Quad-Core 1.2GHz ARM
OS Linux
Operating System Memory 8GB, Industrial Flash
RAM 1GB (512MB shared GPU memory)
Enclosure Powder Coated Aluminum
Working Environment 50 - 95°F (10 - 35°C) Max. 70% RH non-condensing. Avoid direct sunlight.
